Fig.1
Fig.2
Length | Volt | Watt | Fig. | P/number |
---|---|---|---|---|
1000x50 | 230 | 400 | 1 | 7-BA-0100 |
3000x50 | 230 | 1200 | 1 | 7-BA-0101 |
3000x30 | 230 | 900 | 1 | 7-BA-0102 |
Pid controller | 100-240 | 2 | 7-BA-0200 |
Tapes: | |
---|---|
Operating temperature: | -62°C / +260°C |
Thickness: | 1,4 mm |
Length: | 1000 / 3000 mm |
Width: | 50 / 30 mm |
Voltage: | 230V |
Power: | 400 W (calculated for 1000x50 mm) |
Thermocouple: | N/A |
Electrical wires: | Teflon |
Wires length: | 300 mm |
Controller: | |
Type: | Microprocessor |
Input: | Thermocouple, PT100 etc. |
Output 1: | Relè 5A |
Output 2: | Relè 5A |
Power: | 100-240 V AC |
Alarm: | On output 2 |
Display: | Dual digital display |
Dimensions: | 48x48mm |
Custom length available upon request. Please contact our sales office
Bakeout heater tapes are a convenient method of heating parts of the system which are outside the main bakeout zone such as magnetic transporters or which require additional heat such as bellows to fully outgas the system These are made by silicon rubber whit Teflon insulated electrical wires
